System Events in Lightning Framework

System events are fired automatically by the Lightning framework such as during component initialization, attribute value change, rendering etc. All Components can register for system events in their HTML markup.

We can handle these events in the Lightning apps or components, and within the Salesforce mobile app. Here are few examples of system events.

Event Name Description
aura:doneRendering Indicates that the initial rendering of the root application has completed.
aura:doneWaiting Indicates that the app is done waiting for a response to a server request.
aura:locationChange Indicates that the hash part of the URL has
changed.
aura:noAccess Indicates that a requested resource is not accessible due to
security constraints on that resource.
aura:systemError Indicates that an error has occurred.
aura:valueChange Indicates that an attribute value has
changed.
aura:valueDestroy Indicates that a component has been
destroyed.
aura:valueInit Indicates that an app or component has been
initialized.
aura:valueRender Indicates that an app or component has been rendered or
rerendered.
aura:waiting Indicates that the app is waiting for a response to a server request.

Salesforce Lightning Progress Bar

lightning:progressBar component displays the progress of an operation from left to right, like a file download or upload.

Here is an example loads the progress bar on load of the component, and in the JS controller that changes the value of the progress bar.

Lightning Component:

<!--ProgressBar.cmp-->
<aura:component>
     <!--declare handler for render the JS method for Progress bar-->
    <aura:handler name="init" value="{!this}" action="{!c.doInit}"/>
     <!--declare attributes for progress bar value-->
    <aura:attribute name="progress" type="Integer" default="0"/>
    <div class="slds-m-around_xx-large">
        <!--Lightning Progress Bar-->
        <lightning:progressBar value="{!v.progress}"/>
    </div>
</aura:component>

Lightning Component JS Controller:

({
    //Specifying progress === 100 ? clearInterval(interval) : progress + 20 increases
    //the progress value by 20% and stops the animation when the progress reaches 100%
    //The progress bar is updated every 1000 milliseconds.
    doInit:  function (component, event, helper) {
        var interval = setInterval($A.getCallback(function () {
            var progress = component.get('v.progress');
            component.set('v.progress', progress === 100 ? clearInterval(interval) : progress + 20);
        }), 1000);
    }
})

Output:

Salesforce Lightning Tree

lightning:tree component displays visualization of a structural hierarchy, such as a sitemap for a website or a role hierarchy in an organization. Items are displayed as hyperlinks and items in the hierarchy can be nested. Items with nested items are also known as branches.

To create a tree, we have to pass in an array of key-value pairs to the items attribute.
Below are the keys:

  • disabled (Boolean): Specifies whether a branch is disabled. A disabled branch can’t be expanded. The default is false.
  • expanded (Boolean): Specifies whether a branch is expanded. An expanded branch displays its nested items visually. The default is false.
  • href (String): The URL of the link.
  • name (String): The unique name for the item for the onselect event handler to return the tree item that was clicked.
  • items (Object): Nested items as an array of key-value pairs.
  • label (String): Required. The title and label for the hyperlink.

Here is an example of Lightning Tree with list of accounts and respective contacts.

Apex Controller:

public class TreeAuraController {

    @AuraEnabled
    public static List<item> getAccountTree(){

        List<item> items = new List<item>();
        List<Account> acctList = new List<Account>();
        //get list of accounts and respective contacts
        acctList = [SELECT Id, Name, (SELECT Id, Name From Contacts) From Account LIMIT 10];
        for(Account acc: acctList){

            //get contacts of current account record
            List<item> conitems = new List<item>();
            for(Contact c: acc.Contacts){
                //add contact items
                item conitem = new item(c.Name, String.valueOf(c.Id), false, null);
                conitems.add(conitem);
            }

            //add account items
            item accitem = new item(acc.Name, String.valueOf(acc.Id), false, conitems);
            items.add(accitem);
        }
        return items;
    }

    //Item Wrapper Class
    public class item{
        @AuraEnabled
        public String label {get; set;}
        @AuraEnabled
        public String name {get; set;}
        @AuraEnabled
        public Boolean expanded {get; set;}
        @AuraEnabled
        public List<item> items {get; set;}

        public item(String label, String name, Boolean expanded, List<item> items){
            this.label = label;
            this.name = name;
            this.expanded = expanded;
            this.items = items;
        }
    }
}

Lightning Component:

<!--Tree.cmp-->
<aura:component controller="TreeAuraController">
    <aura:handler name="init" value="{!this}" action="{!c.doInit}"/>
    <aura:attribute name="items" type="Object"/>
    <!--Lightning Tree-->
    <div class="slds-m-around_xx-large">
        <lightning:tree items="{!v.items}" onselect="{!c.handleSelect}" header="Account and Contacts"/>
    </div>
    <!--Lightning Spinner-->
    <div>
        <lightning:spinner alternativeText="Processing.." title="Processing.." aura:id="spnr" variant="brand" size="large" />
    </div>
</aura:component>

Lightning Component JS Controller:

({
    doInit: function (component, event, helper) {
        var spinner = component.find("spnr");
        var action = component.get('c.getAccountTree');
        action.setCallback(this, function(response){
            var state = response.getState();
            if(state === 'SUCCESS'){
                //get account and respective contact list, and initialize with items
                component.set('v.items', response.getReturnValue());
                //hide spinner after getting data
                $A.util.toggleClass(spinner, "slds-hide");
            }else{
                $A.util.toggleClass(spinner, "slds-hide");
                alert('ERROR');
            }
        });
        $A.enqueueAction(action);
    },
    handleSelect: function (cmp, event, helper) {
        //return name of selected tree item
        var selectedName = event.getParam('name');
        alert("Selected Name: " + selectedName);
    }
})

Lightning Test App:

<!--Test.app-->
<aura:application extends="force:slds">
    <c:Tree />
</aura:application>

Output:

Salesforce Lightning Spinner

lightning:spinner displays an animated spinner image to indicate that a feature is loading. This component can be used when retrieving data or anytime an operation doesn’t immediately complete.

Here is an example to show the lightning:spinner on click of a button.

Lightning Component:

<!--Spinner.cmp-->
<aura:component>
    <div class="slds-m-around_xx-large">
        <lightning:button label="Click Me" variant="brand" onclick="{!c.openSpinner}"/>
        <div>
            <lightning:spinner class="slds-hide" alternativeText="Processing.." title="Processing.." aura:id="spnr" variant="brand" size="large" />
        </div>
    </div>
</aura:component>

Lightning Component JS Controller:

({
    openSpinner: function (cmp, event) {
        var spinner = cmp.find("spnr");
        $A.util.toggleClass(spinner, "slds-show");
    }
})

Lightning Test App:

<!--Test.app-->
<aura:application extends="force:slds">
    <c:Spinner />
</aura:application>

Output:

We can use lightning:spinner as conditionally, using aura:if or the Lightning Design System utility classes to show or hide the spinner.

The variant attribute changes the appearance of the spinner. If you set variant=”brand”, the spinner matches the Lightning Design System brand color. Setting variant=”inverse” displays a white spinner. The default spinner color is dark blue.

Salesforce Lightning Accordion

lightning:accordion component groups related content in a single container. Only one accordion section is expanded at a time. When you select a section, it’s expanded or collapsed. Each section can hold one or more Lightning components.

Here is an example of Lightning Accordion. I’m retrieving a list of contacts from Salesforce and populating into the Lightning Accordion.

Apex Controller:

public class AccordionAuraController {
    @AuraEnabled
    public static List<Contact> getContacts(){
        List<Contact> contactList = new List<Contact>();
        contactList = [SELECT Id, Name, Email, Phone, MailingStreet, MailingCity, MailingState, MailingPostalCode, MailingCountry From Contact LIMIT 10];
        return contactList;
    }
}

Lightning Component:

<!--Accordion.cmp-->
<aura:component controller="AccordionAuraController">
    <aura:handler name="init" value="{!this}" action="{!c.doInit}"/>
    <aura:attribute name="conList" type="List"/>
    <div class="slds-m-around_xx-large">
        <lightning:accordion>
            <aura:iteration items="{!v.conList}" var="con">
                <lightning:accordionSection name="{!con.name}" label="{!con.Name}">
                    <aura:set attribute="body">
                        <p>Street : {!con.MailingStreet}</p>
                        <p>City : {!con.MailingCity}</p>
                        <p>State : {!con.MailingState}</p>
                        <p>Postcode : {!con.MailingPostalcode}</p>
                        <p>Country : {!con.MailingCountry}</p>
                        <p>Email : {!con.Email}</p>
                        <p>Phone : {!con.Phone}</p>
                    </aura:set>
                </lightning:accordionSection>
            </aura:iteration>
        </lightning:accordion>
    </div>
</aura:component>

Lightning Component JS Controller:

({
    doInit: function(component){
        var action = component.get('c.getContacts');
        action.setCallback(this, function(response){
            var state = response.getState();
            if(state === 'SUCCESS' && component.isValid()){
                //get contact list
                component.set('v.conList', response.getReturnValue());
            }else{
                alert('ERROR');
            }
        });
        $A.enqueueAction(action);
    }
})

Lightning Test App:

<!--Test.app-->
<aura:application extends="force:slds">
    <c:Accordion />
</aura:application>

Output:

Note: The first section in the lightning:accordion is expanded by default. To change the default, use the activeSectionName attribute in lightning:accordion component. This attribute is case-sensitive. If two or more sections use the same name and that name is also specified as the activeSectionName, the first section is expanded by default.
